The rear of the car body can optional with a high water spray gun. The high water spray gun is flexible in operation and can be used to spray objects of various heights. It can be adjusted to be columnar or misty.
SPECIFICATION | ||
Truck Specification | ||
Product Name | 10000Liters dongfeng dust suppression Truck | |
Truck Manufacturer | MANTEN GROUP | |
Overall dimensions (L×W×H) | About 8000*2550*3270mm | |
Chassis Specification | ||
Cabin | DONGFENG,LHD/RHD, A/C | |
Drive type | 4*2 | |
wheelbase | 4500mm | |
Fuel type of engine | Diesel | |
Engine | Model | B190 33 |
Maximum horse power | 190hp | |
Number of cylinders | 6 | |
Emission standard | Euro 3 | |
Gear box | Type | 8 forward &1 rear |
Tyres | Size | 10.00R20 |
Quantity | 6+1 spare tire | |
Upper body specification | ||
Water Tank | Capacity | 12 M3 / 12000Liters /12CBM Water Sprinkler Truck |
Tank Material | 5mm Q235 Carbon steel | |
Function | Equipped with fire valve, water valve, and filter gauze | |
Equipped with front (rear, side) sprinkler (sprinkling width>14m ) | ||
Equipped with rear working platform with water cannon (range>28m) | ||
Head of delivery :100M | ||
Equipped with water pump(suction lift>6m) | ||
Maximum Spray Range(m) | 100 | |
Maximum Spray Height(m) | 30 | |
Spray Volume(L/min) | 0~160 | |
Spray Water Pressure(Mpa) | 2 | |
Nozzle Pitch Angle(°) | -10~60 | |
Horizontal Rotation Angle(°) | -90~90 |
