1. Dongfeng 10 Ton Hook Lift Garbage Truck adopts DUOLIKA chassis,Dongfeng Cummins 140HP engine power,8 forwarder & 1 reverse transmission ,9.00R20 tires.
2. Hooking capacity: 10tons, using Wilber telescopic boom, high-strength boom and structural frame, equipped with imported oil cylinder, sealing ring, multi-way valve, plunger hydraulic oil pump and wireless remote control operator, removable reinforced hydraulic rear leg, manual or wireless remote control operation.
3. One truck can be equipped with some garbage containers for recycling. Garbage containers can be divided into living garbage containers, construction garbage containers, split garbage stations and mobile compression garbage stations.
SPECIFICATION | ||
Truck Specification | ||
Product Name | Dongfeng 10 Ton Hook Lift Garbage Truck | |
Truck Manufacturer | MANTEN GROUP | |
Overall dimensions (L×W×H) | About 7650*2500*3150mm | |
Chassis Specification | ||
Cabin | DUOLIKA cabin,2 persons allowed ,A/C is equipped | |
Drive type | 4x2 | |
wheelbase | 3950/4500/4700mm | |
Fuel type of engine | Diesel | |
Engine | Model | Dongfeng Cummins |
Maximum horse power | 140HP/170HP/190HP | |
Number of cylinders | 6 | |
Emission standard | Euro3/4/5/6 | |
Gear box | Type | Manual,8 forward & 1 rear |
Tyres | Size | 9.00R20 |
Quantity | 6+1 spare tire | |
Upper body specification | ||
Superstructure | Loading capacity | 10TONS |
Dustbin Material | Anti-corrosive steel | |
Hydraulic system | Import or Chinese top brand muti-way valve and cylinders | |
Control method | Manual control or remote control | |
Self-discharging incline angle | 50° | |
Lifting time | ≦60S | |
Unloading time | ≦60S |
