26m dongfeng 4x2 telescopic boom overhead working truck

26m Dongfeng 4x2 Telescopic Boom Overhead Working Truck

1. This Overhead working vehicle adopts Dongfeng chassis ,Boom type is 5 Sections telescopic boom, Max. operation height is 26m.Basket materail is aluminium alloy.

2. The boom is made of high-strength steel plate Baosteel 900 steel, which is compressive and torsion resistant, with excellent quality.

3. Computer controlled LCD can display arm length, working height and working range,Real time display of vehicle operation conditions, automatic amplitude limiting, dangerous work alarm, excellent safety performance.

4. Main supporting hydraulic and electrical components: load sensitive proportional valve, balance valve, controller, etc. are imported parts.

5. The outrigger operation box is equipped with lights to facilitate work at night, and the vehicle level is equipped to ensure the vehicle level and safety.

6. Four in one operation: low position operation, middle position operation, high position operation, Remote control operation. Different construction methods correspond to different operation methods, meeting all operation methods.

Looking for a truck mounted aerial platform factory that can deliver high-quality, reliable products at a competitive price? Look no further than Manten. Our aerial platform trucks are designed with safety and efficiency in mind, and can be customized to meet your specific needs. Contact us today to learn more about our products and how we can help you improve your operations.

Specification Of 26m Dongfeng 4x2 Telescopic Boom Overhead Working Truck

Truck Specification
Product Name26m DONGFENG 4X2 Telescopic boom Overhead working truck
Truck ManufacturerMANTEN GROUP
Chassis Specification
Chassis BrandDongfeng
Drive type4x2,Single cabin
Fuel type of engineDiesel
Maximum horse power120HP
Emission standard3
Gear boxType5T

Upper body specification
Working conditionMaximum operating height26m
Boom Type5 Sections telescopic boom
Outrigger typeOutrigger typeFront V Rear H type. Controlled independently
BasketRated loading weight200kgs
Bucket materialAluminium alloy
Operation systemOperation4 operation mode: Electrical operation of working platform ,ground remote control ,controller in the bucket,and emergency lever.
Control systemElectro hydraulic proportional control system and optional load proportional system can realize double action synchronization and stepless speed regulation
Leveling systemHydraulic automatic leveling
Security configurationAutomatic interlocking device for up and downFor locking up and down the truck to prevent the risk of misoperation
Basket360 degree rotation
Horizontal functionReal time display
Emergency electric emergency pumpWhen the engine and main pump failure, the operator can be sent back to the ground.
Emergency stop deviceFor emergency stop operation
Night safety warning deviceThere are engineering flashing lights and lights on vehicle.
Ignition and flameout of engineThe engine can be ignited and flameout controlled at the turntable and platform
Real time communicationThere is wireless intercom between the platform and the vehicle
