1. The 90T heavy duty crane truck adopts SINOTRUK HOWO 8x4 heavy duty chassis,and the gravity center of the whole truck is lower than 3.6meter for easy access to the height-limited workplaces.
2. The crane jib can be equipped with digital display remote control,counterweight support,winch,etc.
3. The octagonal arm section has better anti-buckling performance and stronger lifting capacity.
SPECIFICATION | ||
Truck Specification | ||
Product Name | SINOTRUK HOWO Heavy Duty 90T Crane Truck | |
Truck Manufacturer | MANTEN GROUP | |
Overall dimensions (L×W×H) | About 11700×2496×3125 mm | |
Chassis Specification | ||
Cabin | HOWO, LHD/RHD, A/C | |
Drive type | 8x4 | |
wheelbase | 1800+4600+1350mm | |
Fuel type of engine | Diesel | |
Engine | Model | SINOTRUK D12.34-30 |
Maximum horse power | 340hp | |
Gear box | Type | 10 forward & 2 rear |
Tyres | Size | 12.00R20 |
Quantity | 12+1 spare tire | |
Upper body specification | ||
Max Lifting Capacity | 90000/4.0 (kg/m) | |
70000/5.0 (kg/m) | ||
35000/9.0 (kg/m) | ||
20000/15.0 (kg/m) | ||
Max Lifting Height | 19m | |
Max Working Radius | 15.5m | |
Rotation Angle | 360º continuous | |
Hydraulic extension boom No.s | 6 stages | |
Outrigger | 6, Extension, Hydraulic operating | |
Options | Winch, Auxiliary Boom,Remote control |
