Dongfeng 4x4 10t Troop Carrier Truck

1. This Army Cargo truck adopts Dongfeng chassis,with 4x4 drive typr,long head single row flat glass cab, all metal welded closed structure, with two supports inside, protective net on the rear window, protective net on the front cover lamp of the cab and air defense lamp.

2. Good off-road performance: the maximum speed is 98km/h, the maximum gradient is 44%, the minimum turning radius is 16m, and the minimum ground clearance is 280mm.

3. It is equipped with military additional devices such as cold start, auxiliary fuel tank, engine oil bucket, water bucket, anti-skid chain, tarpaulin, tool box, etc. The carriage is a high railing iron wood mixed structure. The side plates on both sides cannot be opened. It can be turned into simple long row seats. The rear compartment can be turned down. It is equipped with a reversible climbing ladder. Two chains with adjustable pretightening force are installed in the middle and rear of the vehicle. The bottom plate of the carriage is equipped with a toolbox. The standard combined boom structure is adopted, and the boom can be placed centrally. The bumper is made of 4mm steel plate and can be turned over as a whole, with front anti-collision device.

4. Function configuration: auxiliary oil tank, oil barrel, water barrel, anti-skid chain, tarpaulin, tool box and other military accessories. Traction connection device: traction hook (front/rear), electrical connector, pneumatic brake connector.

Specification Of Dongfeng 4x4 10t Troop Carrier Truck

Truck Specification
Product NameDONGFENG 6X6 Soldier Transport Truck Military Vehicle
Truck ManufacturerMANTEN GROUP
Chassis Specification
Chassis brandDongfeng
Drive type6x6,Left hand drive
wheelbase3600+1250 mm
Fuel type of engineDiesel
EngineModelCummins B190-33
Maximum horse power140KW/190hp
Number of cylinders4
Emission standardEuro 3
Gear boxTypeSix speed transmission,6 speed forward 1 reverse.

Quantity10+1 spare tire
Upper body specification
Loading Capacity20tons
Tank MaterialHigh strength steel and wooden
Standard configurationequipped with Foldable chairs, The rear cargo box is locked and can be opened, green trap with windows and rear door ,tool box.
Colorcan choose by customer
Towing deviceWinch can choose mounted on the front or rear by customer's request,
towing force 44100N
